Changxing KNX Air Quality Sensor

Comprehensive coverage with multiple tests! Real-time control of the air environment!

Changxing KNX Air Quality Sensor is a smart environmental monitoring device with integrated multi-parameter detection. It adopts advanced sensing technology and standard KNX communication protocol, and is capable of accurately detecting key environmental parameters such as temperature, humidity, PM2.5 and carbon dioxide. It can accurately detect key environmental parameters such as temperature, humidity, PM2.5 and carbon dioxide, etc. The product is applicable to a variety of scenarios such as smart home, smart building and commercial office, providing users with comprehensive environmental quality monitoring and intelligent control solutions.

  • Four-parameter simultaneous detection
  • High-precision measurement technology
  • KNX communication protocol support
  • Wide range detection capability
  • Intelligent Alarm Function
Changxing KNX Air Quality Sensor (images 5)
Changxing KNX Air Quality Sensor (images 6)
Changxing KNX Air Quality Sensor (images 7)
Changxing KNX Air Quality Sensor (images 8)
400 +
Service providers nationwide
30+
National Technology Patent
1800+
Clients
24 hours
Online Customer Service Support

Changxing KNX Air Quality Sensor (images 9)
Changxing KNX Air Quality Sensor (images 10)

Multi-scenario use

Detection parameters

  • temp: Range - 10°C to 60°C, accuracy 0.1°C
  • humidity level: Range 0 to 100% RH, Accuracy 0.1% RH
  • PM2.5: Range 0 to 999ug/m³, precision 1ug/m³
  • carbon dioxide CO2Range: 400ppm to 60,000ppm
    • 400ppm-1479ppm: accuracy 1ppm
    • 1479ppm-5144ppm: accuracy 3ppm
    • 5144ppm-17597ppm: accuracy 9ppm
    • 17597ppm-60000ppm: accuracy 31ppm

Electrical parameters

  • Auxiliary power supply: 24~30V, current less than 50mA
  • Bus power supply: 24~30V, current less than 10mA

Exterior Dimensions

Installation: Flush mounting

Size: 90.00mm x 90.00mm

Watch the video to learn more

Changxing KNX Air Quality Sensor (images 11)
Changxing KNX Air Quality Sensor (images 12)
real estate (for sale or rent)

real estate (for sale or rent)

KNX smart switches can be programmed and set to meet individual needs according to different scenarios and user requirements. In buildings, this flexibility allows each occupant to customize the smart home system according to their own habits and needs.Enhanced security: Linked with security systems, KNX smart switches can enhance the security of a home or premises. For example, it can automatically turn on the alarm or shut down related equipment when abnormal conditions are detected, providing a safer living environment for the residents of the building.
Villa/Large Flat

Villa/Large Flat

Villa residents can remotely operate lights, curtains, air conditioning and other equipment in their homes anytime, anywhere via cell phones, tablets and other terminal devices. This feature not only improves the convenience of life, but also allows residents to pre-adjust the environment of their home before leaving home or on the way home.The KNX Smart Switch supports the automatic turning on or off of devices at preset times. For example, it can be set to automatically turn on curtains and lights in the morning and turn them off in the evening, thus helping occupants to develop good living habits and save energy at the same time.Scene mode switching: Different areas in the villa (e.g. living room, bedroom, study, etc.) can switch the working status of the equipment with a single click according to different living scenarios (e.g. movie watching, meeting guests, resting, etc.). This scenario-based control allows each space in the villa to be intelligently adjusted according to actual needs, enhancing the living experience.
five-star hotel

five-star hotel

KNX smart switch supports a variety of preset scene modes, such as "Welcome Mode", "Sleep Mode", "Meeting Mode", etc. Guests can enjoy personalized lighting, curtains, air conditioning and other environmental settings according to their own needs. Guests can switch to the corresponding scene according to their own needs, enjoying personalized lighting, curtains, air conditioning and other environmental settings, thus enhancing the stay experience.Convenient operation: guests can control the equipment in the room through cell phone APP, touch screen and other ways, without the need to manually operate multiple switches, making the operation more convenient and efficient.
Express Hotel/B&B

Express Hotel/B&B

Convenient operation: guests can easily realize the control of lighting, air conditioning, curtains and other equipment through cell phone APP, intelligent voice assistant or the control panel in the room, without the need to manually search for the switch, which greatly improves the convenience of operation.Personalized Settings: The smart switch supports a variety of scene modes, such as "reading mode", "rest mode", etc. Guests can personalize the settings according to their own needs to enjoy a more comfortable stay.Intelligent linkage: some smart switches also support linkage with other smart devices, such as smart door locks, smart speakers, etc. Guests can control multiple devices through a unified platform to realize a smarter living experience.
intelligent building

intelligent building

The KNX system collects and analyzes equipment usage data, providing property management with a basis for energy saving and optimized management. By analyzing the data, the property owner can understand the operating conditions and usage of the equipment, and thus formulate more scientific and reasonable energy management strategies and equipment maintenance plans.

Product Advantage:

Changxing Intelligent KNX solution will help you realize a leap in the efficiency of intelligent management and improve competitiveness, and all our solutions will meet your needs and help you successfully step into the future.

  • Unified global standardized protocols:KNX, as an open international standard, is highly compatible and scalable. This means that it can be seamlessly integrated with a wide range of different types of equipment and systems, whether it is lighting, curtains, air conditioning or security systems, all working together on a unified platform.
  • Powerful Intelligent Functions:1 Remote control: KNX Smart Switch supports various remote control methods through mobile APP, touch screen, etc. Users can control the devices at home anytime and anywhere, providing a more convenient and personalized experience.2 Timing and Scene Mode: The KNX system is able to set up timed tasks and scene modes to automatically adjust the state of the equipment according to the user's living habits and needs, such as automatically adjusting the brightness of the lights, switching on and off the air conditioner, etc., so as to realize intelligent control.
  • Highly flexible and customizable:1 Highly programmable: The KNX system has a high degree of flexibility, so users can program and set up the system according to their own needs to achieve personalized intelligent control.2 Multiple control modes: In addition to the traditional switch control, the KNX system also supports voice control, human body sensing and other control modes to meet the needs of use in different scenarios.
  • Security and Stability:1 Multiple guarantees: The KNX system adopts security measures such as password protection and encrypted communication to guarantee the stability and reliability of the control system. At the same time, the system is also equipped with fault detection and alarm functions, which can detect and deal with equipment faults in time and improve safety.2 Enhanced Protection: The KNX Smart Switch can also be linked to a security system to enhance the safety of your home or premises.

Changxing KNX Air Quality Sensor

Comprehensive coverage with multiple tests! Real-time control of the air environment!

Applicable to a variety of scenarios, providing intelligent solutions for different user groups.

Four-parameter simultaneous detectionIt also supports real-time detection of four key environmental parameters: temperature, humidity, PM2.5 and carbon dioxide, which comprehensively covers the needs of indoor air quality monitoring.
High-precision measurement technologyTemperature detection accuracy is up to 0.1℃, humidity accuracy is up to 0.1% RH, PM2.5 accuracy is up to 1ug/m³, and carbon dioxide detection accuracy is up to 1-31ppm according to different concentration ranges, ensuring the accuracy and reliability of monitoring data.
Wide range detection capabilityTemperature detection range - 10 ℃ to 60 ℃, humidity 0 to 100% RH, PM2.5 0 to 999ug/m³, carbon dioxide 400ppm to 60,000ppm, to adapt to a variety of environmental conditions in the monitoring needs.
KNX standard protocol supportAdopting the standard KNX communication protocol, it can be seamlessly integrated into all kinds of smart buildings and smart home systems to realize interconnection and centralized control among devices.
Changxing KNX Air Quality Sensor KNX-Air-Quality-Sensor-600

From installation to use, from control to maintenance, all
Orientation to meet user needs

Whole-house intelligent connection, easy to enjoy high-quality life, just so understand you!

Flexible Data Transmission ModeSupport active send data cycle settings (in seconds), you can configure the data sending frequency according to the actual demand, network bandwidth use more reasonable.
Intelligent Alarm FunctionSupports high and low alarm threshold settings for temperature, humidity, PM2.5 and carbon dioxide, and automatically sends an alarm signal when the parameters are out of the set range, reminding the user to take appropriate measures in a timely manner.
Alarm object value customizationYou can set the value (1 or 0) to be sent in case of high and low alarms for each type of parameter respectively, which is convenient for linkage control with other intelligent devices.
Standard ETS database supportA standard ETS database file (Test Project Air detector.knxproj) is provided to facilitate project configuration and equipment commissioning by system integrators.
Changxing KNX Air Quality Sensor KNX-Air-Quality-Sensor-1285
Changxing KNX Air Quality Sensor KNX-Air-Quality-Sensor-1285-2
